# How to Find the Slope of a Line on an Excel Graph?

In this article, we will look into how to calculate the slope of a line in an Excel graph.

**Slope of a line** basically determines two parameters :

Attention reader! Don’t stop learning now. If you are an Excel beginner (or an intermediate) and want to learn Excel, Geeksforgeeks brings the perfect course for you to start, **Diving Into Excel**

- The direction of a line.
- The steepness of a line (rise or fall).

It is generally denoted by the letter **“m”. **The equation of a line is given by the expression :

Where,

- m: Slope
- c: Intercept

The mathematical formula for the slope of a line is given by the ratio of **rise** and **run **and in geometry, it is denoted using tan theta.

In this article we are going to discuss various methods on how to find the slope of a line in Excel using a few examples.

**Example 1 :** Consider the dataset having x and y coordinates of a particle moving in 2-D plane.

## Finding Slope:

There are three methods :

1. By using the Excel in-built function **SLOPE**. The syntax is :

=SLOPE(known_ys,knownx_s) known_ys : An array of numeric data points which are dependent. These are dependent on value of horizontal axis. known_xs : An array of numeric data points which are independent.

2. By using the **slope formula** as discussed.

The steps are :

- From the data set take any pair of points.
- The points are (x1, y1) and (x2, y2).
- Use the formula and
**“-“,”/”**operators to find the slope, m.

3. By plotting a **trendline** on the line graph and find its **equation**. From the equation of the trendline we can easily get the slope.

### Method 1: Using Slope function

Here, Y-axis array is stored in B column. The array ranges from B2 to B11.

The X-axis array is stored in A column of the Excel sheet. The array ranges from A2 to A11.

### Method 2: Using Slope formula

Consider the points **(1,2) and (2,4)**. Here, y1=2 and stored in the location B2 and y2=4 stored in location B3 and x1=1 stored in the location A2 and x2=2 stored in the location A3 of the worksheet.

### Method 3:

The steps are :

- Plot the line graph by selecting the dataset and then go to the
**Insert Tab**and then click on**Insert Line or Area Chart.** - The line chart is plotted.
- Now select the chart and then click on the
**“+”**button in the top right corner of the Chart. - The Chart Elements dialog box appears. In this check the
**Trendline**option. This will add the trendline to the existing line graph.

- Now select the Trendline in the chart and right-click on it and then click on
**Format Trendline**.

- The Format Trendline dialog box opens. By default, the trendline will be linear.
- Now, check the box
**“Display Equation on the chart”**.

- This will add the equation of the line on the chart.

The equation of the line is

y=2xBy comparing with the general equation

y = mx + c,we getm=2, c=0

The **slope is 2** for the given line.

**Example 2:** Consider the dataset shown below :

Similarly, by using the trendline and its equation you can easily find** the slope of the line is -0.5**.
