Twsbi 580 Superflex Mod


ugopvn
 Share

Recommended Posts

Inspired by a post on instagram by fpgeeks (http://instagram.com/p/vbuDA_PvwT/?modal=true) about fitting a Nikko G nib on a TWSBI 540, I decided to try it out with my TWSBI 580.



Here are the steps:



1) procure Nikko G nibs



Easy enough, just ordered them on ebay and received them in about a week time.



2) fitting the nib on the TWSBI



Nikko G nibs are not designed for fountain pens. So, in its origina shape, it will not fit the TWSBI 580.



In order to be able to mount it, it is necessary to make the nib shorter and thinner.



The picture below (from left to right) shows the original nib, the nib shortened and finally thinned (by grinding).



Each square in the background has sides 5 mm long (for reference).



http://i722.photobucket.com/albums/ww229/ugopvn/TWSBI%20580%20Superflex/TWBSIFlex2_zps7a0f8379.jpg



Shortening the nib is quickly done with a file.



What takes a lot of time and patience is the thinning.



However, if you persevere, results are very satisfactory as shown below:



http://i722.photobucket.com/albums/ww229/ugopvn/TWSBI%20580%20Superflex/TWBSIFlex1_zpse5351be6.jpg



Once you manage to fit the Nikko G nib on the TWSBI you have a superflex pen.



Railroading is not an issue (unless you want to write real fast) and it is quite enjoyable to use.

Link to comment
Share on other sites

  • Replies 22
  • Created
  • Last Reply

Top Posters In This Topic

  • amberleadavis

    4

  • ugopvn

    2

  • Lamyrada

    3

  • Ambrose Bierce

    2

Top Posters In This Topic

Posted Images

Wow! Great little experiment. You ended up with a pretty nice flexer.

I am the artist formally known as Ambrose Bierce (I recently changed my username from that). If you love me you'll check out my blog http://fpinkgeek.blogspot.com/ or follow me on Instagram and Twitter @Fp_Ink_Geek :D

Link to comment
Share on other sites





I wonder, that link is from abroad US, JetPens has them at this price for a pack of 10! You add shipping it is more or less same, but faster to you.



http://www.jetpens.com/Nikko-Comic-Pen-Nib-G-Model-Pack-of-10/pd/12005

Edited by Lamyrada
Link to comment
Share on other sites

The 580 takes a number 6 nib whereas the mini iirc takes a number 4 nib

Thank you,



I like cheesecake any flavor!

Link to comment
Share on other sites

Correction, the TWSBI 580 takes a #5 nib. The Mini takes a smaller nib, though it's mainly down to narrower nibs (technically it may still be a #5?) - but it's wedged EXTREMELY tightly into the grip section, and next to impossible to remove the nib and feed without bending or breaking fins...

Link to comment
Share on other sites

Ahah ... #5 ... Good to know!



Thank you for sharing this mod with us!



In case you ever wanted to know.... I really want a stacked nib....



http://www.nibs.com/www/WEBSITE%20PICS/Sailor%20Pens/KingEagleNibSideVeiw.jpg

Fountain pens are my preferred COLOR DELIVERY SYSTEM (in part because crayons melt in Las Vegas).



Want to get a special letter / gift from me, then create a Ghostly Avatar



Ink comparisons: The Great PPS Comparison 366 Inks in 2016



Check out inks sorted by color: Blue Purple Brown Red Green Dark Green Orange Black Pinks Yellows Blue-Blacks Grey/Gray UVInks Turquoise/Teal MURKY

Link to comment
Share on other sites





In case you ever wanted to know.... I really want a stacked nib....



http://www.nibs.com/www/WEBSITE%20PICS/Sailor%20Pens/KingEagleNibSideVeiw.jpg

whaaaa.......?

I am the artist formally known as Ambrose Bierce (I recently changed my username from that). If you love me you'll check out my blog http://fpinkgeek.blogspot.com/ or follow me on Instagram and Twitter @Fp_Ink_Geek :D

Link to comment
Share on other sites

That's a Sailor King of Nibs.

Fountain pens are my preferred COLOR DELIVERY SYSTEM (in part because crayons melt in Las Vegas).



Want to get a special letter / gift from me, then create a Ghostly Avatar



Ink comparisons: The Great PPS Comparison 366 Inks in 2016



Check out inks sorted by color: Blue Purple Brown Red Green Dark Green Orange Black Pinks Yellows Blue-Blacks Grey/Gray UVInks Turquoise/Teal MURKY

Link to comment
Share on other sites

Cool! I did something similar with a Watermans #2 semi flex nib. Due to the nib shape I had to file down the black plastic bit of my 580's section so it would fit snugly.




Link to comment
Share on other sites

Nagahara King Eagle



Yep, that's what I meant.



I love that nib.

Fountain pens are my preferred COLOR DELIVERY SYSTEM (in part because crayons melt in Las Vegas).



Want to get a special letter / gift from me, then create a Ghostly Avatar



Ink comparisons: The Great PPS Comparison 366 Inks in 2016



Check out inks sorted by color: Blue Purple Brown Red Green Dark Green Orange Black Pinks Yellows Blue-Blacks Grey/Gray UVInks Turquoise/Teal MURKY

Link to comment
Share on other sites

whaaaa.......?



Any writing samples? Would love to see them - anyone???

“Don't put off till tomorrow what you can do today, because if you do it today and like it, you can do again tomorrow!”

Link to comment
Share on other sites

This pen belongs to FPNer Frank C.



http://sheismylawyer.com/INK/attachments/2013-01-09-Doodle.jpghttp://sheismylawyer.com/INK/attachments/2013-03-31_TLVPP_01_small0.jpg

Fountain pens are my preferred COLOR DELIVERY SYSTEM (in part because crayons melt in Las Vegas).



Want to get a special letter / gift from me, then create a Ghostly Avatar



Ink comparisons: The Great PPS Comparison 366 Inks in 2016



Check out inks sorted by color: Blue Purple Brown Red Green Dark Green Orange Black Pinks Yellows Blue-Blacks Grey/Gray UVInks Turquoise/Teal MURKY

Link to comment
Share on other sites

Interesting - two questions:



How long is the Nikko lasting up against corrosion? I tried something similar with a Gilott 303 once and it rusted up real quick, but obviously that's just a steel nib.



And by thinning are you talking about reducing the width - ie the left and right side in the picture at the top, or are you reducing the thickness/ depth of the nib itself i.e the dimension you can't see in the picture above.

Link to comment
Share on other sites

Interesting - two questions:



How long is the Nikko lasting up against corrosion? I tried something similar with a Gilott 303 once and it rusted up real quick, but obviously that's just a steel nib.



And by thinning are you talking about reducing the width - ie the left and right side in the picture at the top, or are you reducing the thickness/ depth of the nib itself i.e the dimension you can't see in the picture above.





Here are the photos of the nib after 11 days in the inked pen.



As you can the only the lower outer part of the nib (where I ground it) changed color.

However I did not find any rust and there was no discoloration on the inside where it is in touch with the ink and the feeder.



Each square in the picture has 5mm long sides so you can have the scale.



In order to fit it I had to both 1) reduce the length to about 28mm and 2) decrease the thickness of the metal near the bottom (part now black) so that it could slide inside the pen.



It is important to note that Nikko G nibs are made of chrome plated steel. So I guess the chrome plating is preventing fast rusting.

http://i722.photobucket.com/albums/ww229/ugopvn/TWSBI%20580%20Superflex/F9547914-BC1C-4376-9BBC-6C3FF0C36943_zps8adb9324.jpg

Edited by ugopvn
