Swan Mabie Todd Question

[Scrawler]

I have noticed that Swan Mabie Todd pens are designated with numbers like 205/60, 205/63, 645/60 etc.

Does anyone know what these numbers mean. Is there a directory of the meaning of these numbers anywhere? I have tried to find such a listing but cannot.

[Ernst Bitterman]

I don't have an answer, but I sure want to reinforce the question. I've got a post-war 3230, and I have a suspicion as to the meaning behind the number, but I sure would like to see it laid bare.

[Scrawler]

I wonder if it has anything to do with the size and flex of nib. Ernst, is your nib a size 3? If no one knows the answer to this, I am going to try to deduce it. My first hypothesis is that the first digit refers to the nib size.

[Bo Bo Olson]

Nib size must be there somewhere.

I just read Lambrou' fountain pen book '89 edition on Swan pens and nothing on the numbers, perhaps in a newer edition.

The @ 1895, first models a 3 and a 5 were nib size and a pen to match the nib size.

Nothing on the numbers in the 18 pages of repairing a Swan in "The Repair Book'.



There is some info somewhere. I have seen it....I once chased Swans for six weeks....slow enough not to catch any...which happens when one is cheap enough.



I don't have a link. I have seen posts talking about it...try the advanced search "Swan numbers" perhaps that will give you something.

[Malcy]

I can give some information on post war swan numbering.



They have four digit numbers usually stamped around the end of the barrel e.g. 4660



first numeral is the filler type. 3 = lever filler, 4 = leverless - a twist filler

second numeral is nib size between 1 and 6, pen bodies get larger with the nib size. There are anomalies, I have seen 32xx marked pens with size 3 nibs several times.

The third numeral ranges from 2 to 6 but I have not seen a relationship yet, it may be nib type or finish but it doesnt make sense.

Numeral four is usually 0 but can be 1. Again I cannot work out what it represents perhaph celluloid or bhr as both were used post war.



So a 4450 is a leverless pen with a size four nib.



I hope that this helps.



Posted from sunny Austria by Android phone - please excuse any typos!

[Fermata]

Nice job Malcy - and enjoy Austria, Vienna is Number 1 on my list of places to see.



The numbering worked for a Twist filler of mine but not a MB Blackbird which was GG 61!



Different numbering system for Blackbirds perhaps?

Edited August 26, 2011 by Parkette

[Malcy]

I forgot something.



The M,T&Co headquarters and factory in London along with paperwork, records etc was destroyed by bombing during WWII. So little detail on pre war production exists as I understand.

[Ernst Bitterman]

That squares with mine, at least-- 3230 is a lever-filler, #2 point (or... should be; a little Frankensteinish at the moment), and perhaps the last two digits can be made to mean a grey celluloid body.



But that doesn't address the apparent lunacy of the pre-war XXX/YY codes.

[Malcy]

No, the pre-war codes are very different. I have been concentrating on post-war Swans but I know that there are a lot of different pre-war codes.



I can say that the prefix SM stands for Swan Minor.

[Scrawler]

That squares with mine, at least-- 3230 is a lever-filler, #2 point (or... should be; a little Frankensteinish at the moment), and perhaps the last two digits can be made to mean a grey celluloid body.



But that doesn't address the apparent lunacy of the pre-war XXX/YY codes.

No, indeed. I am very curious about those, because there really seems to be an excess of digits for the information that needs to be conveyed. I do not suppose any part of that could be a date. I have a 205/60 which has a #2 nib. It is a slightly flexible stub. But as one can with reasonable ease change the point, having a code that refers to the point on the pen body makes not sense.

[Scrawler]

OK so after much reading this is what I think so far:



abb/cc



a=nib designation

bb=pen body style (shape and type 05 = Self filler)

cc=color or pattern (59 = italian marble, 60 = BCHR, 63 = russet and jade, 84 = Jade Snake Skin celluloid 86 = B&W snakeskin)

Edited August 26, 2011 by Scrawler

[Ernst Bitterman]

Reading... WHERE? Hungry brains want to know!

[Scrawler]

Reading... WHERE? Hungry brains want to know!

Google is my friend. I did all sorts of searches on Swan pens. For instance "SWAN SM205". I found items for sale and compared images and descriptions.

[jor412]

OK so after much reading this is what I think so far:



abb/cc



a=nib designation

bb=pen body style (shape and type 05 = Self filler)

cc=color or pattern (59 = italian marble, 60 = BCHR, 63 = russet and jade, 84 = Jade Snake Skin celluloid 86 = B&W snakeskin)





This is great. I have an SM 100/60, w/ a #1 nib It's a lever-fill in BCHR. Perhaps if we pool our different models, we might come up with a tentative list while also accounting for frankenswans.

[Scrawler]

jor412, this is a good idea. As we collect more info from others we should keep updating this list. Photo examples of body colour/pattern/type might be a good idea.

[Azuniga]

Malcy,

thanks for the information very useful !!



Jor412

Great idea, i will take some shots and post them



Best, Ariel

[jor412]

Here's a previous thread on the Swan. Another FPN member had needed help figuring out the date and I have the same model so I posted a pic.



EDIT: I also included everything imprinted on the barrel, nib, & section; plus a quote from the papers that came with it.

Edited August 27, 2011 by jor412

[markiv]

Here is what I gather via a quick look over eBay

http://i.imgur.com/dwXb1.png

Edited August 28, 2011 by markiv

[Azuniga]

Here is what I gather via a quick look over eBay

http://i.imgur.com/dwXb1.png



Great !! Thank you...

[jor412]

Here is what I gather via a quick look over eBay

http://i.imgur.com/dwXb1.png



Great !! Thank you...



Wow excellent. I have another Swan w/o a number and double checked that against the ebay pics of black ones with #2 nibs that you have listed here. It isn't the same pen. Here's a pic.



http://i1228.photobucket.com/albums/ee441/ior412/mabieclosed.jpg
