Noodler's Ink Bulletproof-Ness Test

noodler noodlers bulletproof resistant

  • Please log in to reply
15 replies to this topic

#1 MadAsAHatter

MadAsAHatter

    Near Mint

  • Member - Gold

  • PipPipPip
  • 47 posts
  • Location:Louisiana
  • Flag:

Posted 20 February 2020 - 13:52

I work in a regulatory chemistry lab so having basically everything resistant ink is a must for archival & forgery purposes.  Where I'm at we're under EPA regulations (vs. ISO or TNI) so it only says indelible ink.  The majority of the inks I use are Noodler's bulletproof inks & have been approved by our QA/QC officer.  Since Noodler's inks are not ISO or anything else certified I decided to do my own tests with some of our common solvents in the lab in case an auditor ever asks about it.  My test wasn't anything super scientific but should be enough to show anyone the permanency of the ink.  While I was at it I figured it's nice to share my results with you.



The test:  I filled a beakers with 6 common solvents we use in our lab.  The solvents are Hexane, Acetone, Ethyl Acetate, Methylene Chloride, methyl tert butyl ether(MTBE), and Methanol.  I wrote the name of each ink on plain copy paper and let it dry overnight.  I then let it soaked each piece of paper in the corresponding solvent for at least 1 minuet.  During the soak I agitated the piece of paper several times in an attempt to force the ink to wash off.  And for reference I wrote the name of the solvent the paper was placed in with a black Bic pen.  After soaking I removed the paper and placed it on the counter to dry.



Edit: One other note, the ink labeled Noodler's Teal is a 1:4 mix of Bad Green Gator and Bad Blue Heron respectively.



This first picture is of everything before it was soaked in solvent.  And please forgive my bad handwriting as I was scribbling the names and wasn't worried about penmanship.

Attached Images

  • Ink Before Solvent.jpg

Edited by MadAsAHatter, 21 February 2020 - 13:45.


Sponsored Content

#2 MadAsAHatter

MadAsAHatter

    Near Mint

  • Member - Gold

  • PipPipPip
  • 47 posts
  • Location:Louisiana
  • Flag:

Posted 20 February 2020 - 13:53

Now for the results:



This picture is after the paper was soaked in solvent and allowed to dry.



In most all cases the ink stayed put regardless of the solvent it was placed in.  Noodler’s Zhivago, Lemontov, Blue-Black, Air Corp Blue Black, and Dostoyevsky had very slight running when placed in Methanol but nothing significant.  The most significant result was Tolstoy.  It remained intact in Hexane and MTBE, Had slight feathering out an Ethylacetate and nearly washed out all together in Acetone, Methylene Chloride & Methanol.



Attached Images

  • Ink After Solvent.jpg


#3 MadAsAHatter

MadAsAHatter

    Near Mint

  • Member - Gold

  • PipPipPip
  • 47 posts
  • Location:Louisiana
  • Flag:

Posted 20 February 2020 - 14:01

Here are some better Pics of the results:





Attached Images

  • Hexane.jpg
  • Acetone.jpg
  • Ethyl Acetate.jpg


#4 MadAsAHatter

MadAsAHatter

    Near Mint

  • Member - Gold

  • PipPipPip
  • 47 posts
  • Location:Louisiana
  • Flag:

Posted 20 February 2020 - 14:05

Apparently I'm bad at posting pics on the forum but at least you can see the results  :D

Attached Images

  • Methylene Chloride.jpg
  • MTBE.jpg
  • Methanol.jpg


#5 Eclipse157

Eclipse157

    Hoarder of ink

  • Member - Gold

  • PipPipPipPipPipPip
  • 200 posts
  • Flag:

Posted 20 February 2020 - 14:39

Wow! Thanks for doing this, so very interesting and appreciated :thumbup:



#6 Arkanabar

Arkanabar

    Ain't I a stinker?

  • Member - Gold

  • PipPipPipPipPipPipPipPipPip
  • 2,764 posts
  • Flag:

Posted 20 February 2020 - 14:43

I once hung HoD in a north-facing window long enough for the paper to start to yellow.  It lost absolutely no color.



Try soaking or boiling them in ammonia, if you will; I'd appreciate that.



And I'm sure the Ink Comparisons forum would appreciate this.



#7 txomsy

txomsy

    Vintage

  • Member - Gold

  • PipPipPipPipPipPipPip
  • 705 posts
  • Flag:

Posted 20 February 2020 - 14:56

Wow! Wonderful work. And most interesting for those of us who value permanence.



#8 PAKMAN

PAKMAN

    Say that again, I have a pen here somewhere...

  • FPN Super Moderators

  • PipPipPipPipPipPipPipPipPipPipPipPipPip
  • 27,808 posts
  • Location:Arkansas, USA
  • Flag:

Posted 20 February 2020 - 15:30

Interesting results! Thanks for the comparison!


PAKMAN


minibanner.gif             fpn_1321906507__vanness_sign.jpg

                  My Favorite Pen Restorer                            My favorite Brick and Mortar

                                                                   now selling online!


#9 Intensity

Intensity

    Antique

  • Member - Gold

  • PipPipPipPipPipPipPipPipPip
  • 2,086 posts
  • Location:U.S.A.
  • Flag:

Posted 20 February 2020 - 20:14

Thank you very much for sharing this experiment! The colors being compared on those sheets is also a great reference. Now considering getting a bottle of Lermontov. Did Lermontov used to be violet and then reformulated to blue?

Edited by Intensity, 20 February 2020 - 20:20.

“I admit it, I'm surprised that fountain pens are a hobby. ... it's a bit like stumbling into a fork convention - when you've used a fork all your life.”


#10 inkstainedruth

inkstainedruth

    Ancient Artifact

  • Member - Gold

  • PipPipPipPipPipPipPipPipPipPipPipPip
  • 17,667 posts
  • Flag:

Posted 20 February 2020 - 20:34

Thanks for doing this.  Proves what I've thought (and said) all along -- Kung Te Cheng is pretty much EVERYTHING proof!  Good to know about 54th Massachusetts and Heart of Darkness -- I like those as well.

Ruth Morrisson aka inkstainedruth


"It's very nice, but frankly, when I signed that list for a P-51, what I had in mind was a fountain pen."

#11 Mercian

Mercian

    Egregiously prolix

  • Member - Gold

  • PipPipPipPipPipPipPip
  • 544 posts
  • Location:Poundland
  • Flag:

Posted 20 February 2020 - 21:47

Interesting tests  :thumbup:
I guess we can’t really quibble with the makers’ claims about the robustness of these inks :)



Has anyone here previously posted images of similar tests performed with the solvents that are commonly available outside of labs (ethanol, bleach, ammonia, and sodium hydroxide)?





Foul in clear conditions, but handsome in the fog.


#12 Fuzzy_Bear

Fuzzy_Bear

    Collectors Item

  • Member - Gold

  • PipPipPipPipPipPipPipPip
  • 1,117 posts

Posted 23 February 2020 - 17:44

That is cool! I've only done sun fading tests.
The glory of the young is their strength; the gray hair of experience is the splendor of the old.

#13 GardenWeasel

GardenWeasel

    Antique

  • Member - Gold

  • PipPipPipPipPipPipPipPipPip
  • 1,664 posts
  • Location:Columbia, SC

Posted 23 February 2020 - 19:05

Wonderful review! Thank you!


Posted Image

#14 TSherbs

TSherbs

    Donor Pen

  • Member - Gold

  • PipPipPipPipPipPipPipPipPipPip
  • 3,921 posts

Posted 23 February 2020 - 23:31

Excellent. Thanks.

#15 IThinkIHaveAProblem

IThinkIHaveAProblem

    Rare

  • Member - Gold

  • PipPipPipPipPip
  • 118 posts
  • Flag:

Posted 11 March 2020 - 23:29

Late to the party but wanted to thank you for posting this
Just give me the Parker 51s and nobody needs to get hurt.

#16 Gloucesterman

Gloucesterman

    Transformation Coach

  • Member - Gold

  • PipPipPipPipPipPipPipPipPip
  • 2,280 posts
  • Location:Gloucester, MA
  • Flag:

Posted 03 April 2020 - 18:41

Very impressive evaluation of the "bullet-proof-ness" of these inks. I liked the details and the images.

Thank you so much.

To all -- Stay well and safe in these challenging times


“Don't put off till tomorrow what you can do today, because if you do it today and like it, you can do again tomorrow!”
