Measured Ink Capacity


  • Please log in to reply
36 replies to this topic

#1 tonybelding

tonybelding

    Donor Pen

  • Member - Gold

  • PipPipPipPipPipPipPipPipPipPip
  • 3,459 posts
  • Flag:

Posted 24 June 2014 - 12:22

This seems like a good time to update my ink capacity measurements.  I really thought I'd posted these on FPN before, but a search didn't turn them up.  I measure the capacity by filling the pen with water, then expel the water and measure it using a graduated syringe.  I make no attempt to account for water remaining in the feed, so my numbers will be slightly lower than those calculated by weight.  I also decided to round everything to the nearest 0.1 cc, since haggling over hundredths would be silly and possibly misleading.



0.4 cc - Pilot Vanishing Point (with included converter)

0.5 cc - Sheaffer Snorkel

0.6 cc - Schmidt K5 converter

0.7 cc - Sheaffer Imperial (touchdown filler)

0.8 cc - Esterbrook J

0.8 cc - Sheaffer squeeze converter

1.0 cc - Sheaffer Skrip cartridge *

1.0 cc - Sheaffer Triumph (Vacuum-Fil)

1.0 cc - TWSBI Diamond 530

1.1 cc - Bexley Corona

1.1 cc - Pelikan M200

1.1 cc - Lamy 2000

1.1 cc - Parker 51 (aerometric)

1.2 cc - TWSBI Vac 700 (single stroke fill)

1.6 cc - Parker 51 (vacumatic)

1.7 cc - Gate City Belmont

1.9 cc - Wality eyedropper (standard size)

2.0 cc - TWSBI Vac 700 (two stroke fill)

2.2 cc - Gate City New Postal Jr. (bulb-filler)

2.5 cc - Edison Glenmont (bulb-filler)

3.0 cc - Wality eyedropper (oversized)

6.4 cc - Varuna Gajendra (giant eyedropper)



* Sheaffer cartridges are supposed to come from the factory with 1 cc, but when refilling them I can get about 1.4 cc in.



It's interesting to note how many classic fountain pens cluster right around 1.0-1.1 cc capacity.



We must remember that the amount of writing you can get from a pen is not a simple function of how much ink it holds.  A smaller nib tip, a drier nib and a more consistent feed can all stretch your writing.  The Sheaffer Snorkel, for example, is known for having pretty good write-out, despite the small amount of ink it holds.  It's the Prius of fountain pens!



The TWSBI Vac 700 is listed twice.  Most vac-fill pens are intended to fill normally with a single stroke of the plunger.  There is also a somewhat tricky two-stroke technique to fill the entire reservoir, and TWSBI sell a special ink bottle to make it easier and safer to perform without spilling ink.  So, I decided to measure it both ways.



Also, more ink is not always better.  Whenever go you above 2 cc, then you need to start worrying about ink surges which may overwhelm the feed, then your pen may burp up drops of ink onto the page.  I never saw that happen with my New Postal Jr, but I have seen it a couple of times with the Edison Glenmont.




Sponsored Content

#2 Lyander0012

Lyander0012

    One Who Wanders With The Water

  • Member - Gold

  • PipPipPipPipPipPipPipPip
  • 1,063 posts
  • Location:Pasig City, PH
  • Flag:

Posted 24 June 2014 - 13:07

This is an immensely useful thread. Thanks for posting!


"The price of an object should not only be what you had to pay for it, but also what you've had to sacrifice in order to obtain it." - The Wisdom of The Internet


#3 Ernst Bitterman

Ernst Bitterman

    Nil Magnum Nisi Bonum

  • Member - Gold

  • PipPipPipPipPipPipPipPipPipPipPip
  • 8,000 posts
  • Location:The Flat Bit, Canada
  • Flag:

Posted 24 June 2014 - 13:31

I use the same method for capacities on my site; I got 0.5 ml for the VP, but that's probably down to personal inclination in rounding. I'm in overall agreement with all else, though. Snorkels and 51s go a LONG time between fills.

Ravensmarch Pens & Books
It's mainly pens, just now....

Oh, good heavens. He's got a blog now, too.







#4 Bo Bo Olson

Bo Bo Olson

    Ancient Artifact

  • Member - Gold

  • PipPipPipPipPipPipPipPipPipPipPipPip
  • 19,000 posts
  • Location:Germany

Posted 24 June 2014 - 15:56

I have measurements memorized from some other poster. Seeing how I'm never going to do it my self....much too lazy. I'll take any one's efforts.



Pelikan 200/400 =1.27 ml, 600/800 =1.37....1000 =1.47 and a MB 149 at =1.60. That last one holds only as much as one of the older Sheaffer cartridges of 1.60. That was a surprise. :o

Or that two short international cartridges of @0.74 = more than in a giant 149. :yikes:

It was defiantly a shock to learn some cartridges hold more than a 200/400 Pelikan; the day the myth died. B) .


Everyone says poor Mozart dead at only 36. None say poor Mendelson, dead at only 38. His family only allowed him to start at 20, but before, musicians use to come to the Mendelson garden to steal the music of Mendelson and his sister. A good artist also, can still buy prints of his famous Scottish drawings in Scotland.



www.nibs.com/blog/nibster-writes/nibs-germany      Info on Bock nibs



The cheapest lessons are from those who learned expensive lessons. Ignorance is best for learning expensive lessons.



Pens/inks/paper on hold for a year....new addiction pocket watch chains. :happyberet:


#5 Cepasaccus

Cepasaccus

    Vintage

  • Member - Gold

  • PipPipPipPipPipPipPip
  • 755 posts

Posted 28 June 2014 - 16:52

Some numbers from me:

0.2 cc - Waterman's Ideal 452 1/2 V (Lever filler)
0.4 cc - Kaweco with mini converter
0.5 cc - Parker Duofold Lady (Pushbutton filler)
0.6 cc - Pilot Capless w CON-50
0.7 cc - Rheinperle 475 F (Pushbutton filler)
0.8 cc - Heiko Primus, Junior, Sprint w cartridge
0.8 cc - Markan 65 Exquisit (Aerometric filler)
0.8 cc - Montblanc 144 with converter
0.8 cc - Noodler Creeper Flex
0.8 cc - Waterman's Ideal 52 (Lever filler)
1.1 cc - DeLaRue Onoto (Plunger filler)
1.1 cc (up to 2.8 cc) - Parker Duofold Senior Streamlined (Pushbutton filler)
1.2 cc - Geha Schulfueller 780 (Piston filler)
1.2 cc - Gold-Fink Liebling (Safety eyedropper filler)
1.3 cc - Sheaffer Lifetime Junior Flattop (Lever filler)
1.3 cc - Waterman's Ideal 52 (Lever filler)
1.4 cc - Montblanc 146 (Piston filler)
1.4 cc - Parker "51" Standard (Aerometric filler)
1.5 cc - Astoria No. 1 (Safety eyedropper filler)
1.5 cc - Mercedes 75 06 (Piston filler)
1.5 cc - Waterman's Ideal 12 PSF (Lever filler)
1.5 cc - Waterman's Ideal 42 (Safety eyedropper filler)
1.8 cc - Parker Duofold Senior (Pushbotton filler)
2.3 cc - Mabie Todd & Co The Swan (Eyedropper filler)
2.6 cc - Waterman's Ideal 44 (Safety eyedropper filler)
3.2 cc - Waterman's Ideal 45 (Safety eyedropper filler)
3.3 cc - Mabie, Todd & Co. pre-Swan with over/under-feed, capped 17cm long, diameter 8mm (Eyedropper filler)

The capacity of the lever filler seems to depend on the ink sac and not all have the optimum capacity, what can be seen on the Watermans:

0.8 cc - Waterman's Ideal 52 (Lever filler)
1.3 cc - Waterman's Ideal 52 (Lever filler)

And maybe also the mechanism itself is not the best, because with some fiddling much ink can be squeezed into a pen, like this Duofold:

1.1 cc (up to 2.8 cc) - Parker Duofold Senior Streamlined (Pushbutton filler)

Cepasaccus

Edited by Cepasaccus, 28 June 2014 - 16:59.


#6 VivienR

VivienR

    Collectors Item

  • Member - Gold

  • PipPipPipPipPipPipPipPip
  • 1,208 posts
  • Flag:

Posted 05 July 2014 - 12:59

Recently cleaned and refiled with different color a Parker long cartridge I not measured exactly but it was close to 2ml ink capacity.



#7 arran

arran

    Extremely Rare

  • Member - Gold

  • PipPipPipPipPipPip
  • 390 posts
  • Location:Flanders
  • Flag:

Posted 05 July 2014 - 18:39

Modern conid bulkfillers : 2,5 to 3 ml !!
Reliable pens for sure

#8 Namo

Namo

    Antique

  • Member - Gold

  • PipPipPipPipPipPipPipPipPip
  • 2,324 posts

Posted 12 November 2014 - 15:56

Lamy 2K is definitly more in the 1.3 area. Lamy 27m: said to hold 1.5ml (according to Myu's review).

Marlen Aleph: barely 1ml. Piston filler and a rather thirsty nib.


amonjak.com


free 70 pages graphic novel. Enjoy!


#9 wvbeetlebug

wvbeetlebug

    GO EERS!!!

  • Member - Gold

  • PipPipPipPipPipPipPipPipPip
  • 2,168 posts
  • Location:Winston-Salem, NC (Home of the Krispy Kreme!)
  • Flag:

Posted 17 November 2014 - 00:20

Thanks for posting!


:happycloud9:



Cathy L. Carter



Live. Love. Write.


#10 KBeezie

KBeezie

    Gerbil Charmer

  • Member - Gold

  • PipPipPipPipPipPipPipPipPipPipPip
  • 5,424 posts
  • Location:Grand Rapids, Michigan
  • Flag:

Posted 17 November 2014 - 04:00

My Parker 51 Vacumatic (Cordovan Brown, 1948 body) holds 2.0ml (consistently).
My Montblanc 225 (Piston), about 1.4 ml.

#11 PS104

PS104

    Collectors Item

  • Member - Gold

  • PipPipPipPipPipPipPipPip
  • 903 posts

Posted 17 November 2014 - 04:51

+1 for starting this thread. Thanks



#12 Tanzanite

Tanzanite

    Collectors Item

  • Member - Gold

  • PipPipPipPipPipPipPipPip
  • 1,094 posts
  • Flag:

Posted 17 November 2014 - 04:59

Is cc the same as ml?

#13 KBeezie

KBeezie

    Gerbil Charmer

  • Member - Gold

  • PipPipPipPipPipPipPipPipPipPipPip
  • 5,424 posts
  • Location:Grand Rapids, Michigan
  • Flag:

Posted 17 November 2014 - 05:00

Is cc the same as ml?



Yes, 1 Milliliter is equal to 1 Cubic Centimeter.



#14 Tanzanite

Tanzanite

    Collectors Item

  • Member - Gold

  • PipPipPipPipPipPipPipPip
  • 1,094 posts
  • Flag:

Posted 17 November 2014 - 05:14

Aha. Thank you. I did not know that cc stood for cubic centimeter.

#15 brunico

brunico

    Collectors Item

  • Member - Gold

  • PipPipPipPipPipPipPipPip
  • 1,178 posts
  • Location:London
  • Flag:

Posted 17 November 2014 - 11:14

Aha. Thank you. I did not know that cc stood for cubic centimeter.



There's an online cc -> ml converter if you ever get stuck...



:)



#16 Mr. JW

Mr. JW

    Rare

  • Member - Gold

  • PipPipPipPipPip
  • 153 posts
  • Location:Boston, MA
  • Flag:

Posted 17 November 2014 - 14:47

I tested out my TWSBI Mini over the weekend. I measured three times and came up with .8 cc each time.


Jeff


#17 Cepasaccus

Cepasaccus

    Vintage

  • Member - Gold

  • PipPipPipPipPipPipPip
  • 755 posts

Posted 17 November 2014 - 18:14

0.4 cc - Mabie, Todd & Co. Ltd. S.F.2B(?) (Ring top, lever filler)
0.8 cc - Sheaffer PfM III
1.4 cc - Hero 616 Copy (Short ink sac type)
1.6 cc - DeLaRue Onoto 560 (Plunger filler)
1.8 cc - Perry & Co. Alexandria No. 520 (Eyedropper filler)
2.0 cc - Mabie, Todd & Bard The Swan 3012 Pocket Pen (Eyedropper filler)
2.2 cc - Waterman's Ideal 12 (1911-1917, safety eyedropper filler)
2.5 cc - Waterman's Ideal 46 (Safety eyedroppfer filler)




#18 Tanzanite

Tanzanite

    Collectors Item

  • Member - Gold

  • PipPipPipPipPipPipPipPip
  • 1,094 posts
  • Flag:

Posted 17 November 2014 - 21:07

There's an online cc -> ml converter if you ever get stuck...

:)


Thank you. No, I just did not know what cc was short for because my first language is not english. I know what a cubic centimeter is :)

#19 Tanzanite

Tanzanite

    Collectors Item

  • Member - Gold

  • PipPipPipPipPipPipPipPip
  • 1,094 posts
  • Flag:

Posted 17 November 2014 - 21:12

That was actually funny Brunico :) 1 cc is 1 ml. Hmmm... how many ml might 5 cc be... :D

#20 Namo

Namo

    Antique

  • Member - Gold

  • PipPipPipPipPipPipPipPipPip
  • 2,324 posts

Posted 20 November 2014 - 23:43

Lamy 2K is definitly more in the 1.3 area. Lamy 27m: said to hold 1.5ml (according to Myu's review).
Marlen Aleph: barely 1ml. Piston filler and a rather thirsty nib.


A little follow up: the Lamy 27m hold 1.6ml+, unscientific measurement, but with a eyedropper graduated to the tenth of ml.

amonjak.com


free 70 pages graphic novel. Enjoy!
